| Max. Drilling Depth | 200m |
| Drilling Hole Dia. | 90-315mm |
| Working Pressure | 1.7-3.0Mpa |
| Air Consumption | 17-35m3/min |
| Drill Pipe Length | 3m |
| Drill Pipe Dia. | 76mm/89mm |
| Axial Pressure | 4T |
| Lifting Force | 14T |
| Lifting Speed | 2.5m/min |
| Push Speed | 0.5-5m/min |
| Fast lifting Speed | 35m/min |
| Max.Rotation Torque | 4500-6500Nm |
| Rotation Speed | 50-70r/min |
| Working Hoist Lifting Force | 1.5T |
| Mud Pump Flow Rate | 20L/min (optional) |
| High Pressure Hydraulic Legs Stroke | 1.5m |
| Drilling Efficiency | 10-35m/h |
| Travel Speed | 2Km/h |
| Grade ability | 30° |
| Weight | 5.4T |
| Dimension | 3.9x1.7x2.15m |
| Diesel Engine | 77KW(Yuchai ) |
| Application formation | loose layer or bedding rock |
| Drilling Method | Top Hammer Hydraulic Rotating and feeding, Down the hole hammer or mud pump drilling |
Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
Glorytek Drill is one of the most important member of “Sundrill Corporation”.Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
Q: How can we choose a suitable water well drill rig?
A: We normally recommend a suitable model according to drilling depth, drilling hole dia. and layer condition on site.
Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.
Q: What is your payment terms?
A: We can accept T/T,L/C.
Q:.What is your MOQ? How long is the delivery time?
A: Our MOQ is 1 sets. Normally for drill rig, the delivery time is about 25-30 days after receiving payment, the drilling tools would be about 15 days.
Q:. How long is the warranty?
A: The guarantee period for mainframe is one year (excluding the quick wear parts).
Q: Can we print my Logo on the products?
A: Yes, we can. We support OEM .
