Our drill rig machines boast a maximum working pressure of 25 Bar(362.5 Psi), which makes them capable of handling tough drilling tasks with ease. They come equipped with a fuel tank capacity of 1,000 L, which ensures uninterrupted drilling operations for longer periods.
The drill pipe length of our machines is 7 M ( Optional 5 / 6 M ), and the drill pipe OD is 114 Mm ( Optional 102 / 127 Mm ). This versatility ensures that our machines can be customized to meet the specific drilling needs of our clients.
Our Integrated Blasthole drilling rig is a powerful machine that can drill blastholes of up to 229 mm in diameter. It is designed to handle drilling tasks in both soft and hard rock formations. The machine is fully hydraulic, which means that all drilling operations are controlled by hydraulic power. This makes it highly efficient and reliable, with minimal downtime.
The Fully hydraulic DTH drilling rig is another high-performance machine that is designed for drilling tasks in hard rock formations. The machine is equipped with a powerful hydraulic system that controls all drilling operations, making it highly efficient and reliable. The machine is capable of drilling holes of up to 165 mm in diameter.
Our Air Compressor DTH Drill Rig is a versatile machine that is designed for drilling tasks in both soft and hard rock formations. The machine is equipped with a powerful air compressor that delivers high-pressure air to the drilling bit, making it highly efficient and reliable. The machine is capable of drilling holes of up to 165 mm in diameter.
At our company, we are committed to delivering high-quality drill rig machines that meet the specific needs of our clients. Our machines are built to last, with a focus on performance and reliability. Contact us today to learn more about our range of drill rig machines and how they can benefit your business.
| Technical Parameter | Value |
|---|---|
| Product Name | Integrated Drill Rig / Air Compressor DTH Drill Rig / Air Compressor on Board DTH Drill Rig |
| Drill pipe OD | 114 Mm (Optional 102 / 127 Mm) |
| Ground clearance | 420 Mm |
| Slope climbing ability | 25 Degree |
| Maximum working pressure | 25 Bar (362.5 Psi) |
| Recommended DTH hammer size | 6" (Optional 7"/8") |
| Maximum torque | 5,600 N.m |
| Drill pipe handling capacity | 4+1 |
| Fuel tank capacity | 1,000 L |
| Hole range | 152 - 203 Mm |
| Rotation speed | 0 - 80 Rpm |
Our Drill Rig Machines are designed with advanced technology and are built to last. However, we understand that sometimes technical issues can arise, which is why we offer comprehensive technical support and services to ensure your machine is running at optimal performance.
Our technical support team is available to answer any questions you may have about your Drill Rig Machine. We also offer on-site support for more complex issues that cannot be resolved over the phone or via email.
In addition to technical support, we also offer a range of services to help maintain and repair your Drill Rig Machine, including regular maintenance checks, repairs, and replacement parts. Our team of skilled technicians are trained to handle any maintenance or repair needs, and we use only genuine parts to ensure the highest level of quality and performance.
By choosing our Drill Rig Machines, you can be confident that you have a reliable and efficient machine, with access to top-notch technical support and services to keep it running smoothly for years to come.
